Ultrafiltration Membrane Filter Water Purifier Machine Water Treatment UF Filtration System

Name: Ultrafiltration Membrane Filter Water Purifier Machine Water Treatment UF Filtration System
Brand: HUAYU
Price: 1 USD

China Ultrafiltration Membrane Filter Water Purifier Machine Water Treatment UF Filtration System wholesale

video outgoing-inspection : Provided

machinery test report : Provided

core components : Pump, Engine, motor, PLC

Place of Origin : Hebei, China

Brand Name : HUAYU

warranty : 1 Year

productivity : 5000L/Hour

weight (kg) : 1000

Processing Type : Reverse Osmosis

Dimension(L*W*H) : 160 70 70

Power : 70 KW

Voltage : 220V, 380V, 110V

Application : Wastewater treatment

Product name : uf membrane system

Core Technology : UF process

Certification : ISO9001:2015

Lead Time : About 21 days

Contact Now

Product Description

Our company specializes in designing ultrafiltration membrane systems in our laboratory, with an ultrafiltration equipment capacity of 1000L/H. The system utilizes municipal tap water as the raw water source, and the conductivity of the RO water purifier for industrial use is maintained below 10 µS/cm. With the robust performance and strong capabilities of our 10,000 LPH UF system, we are currently engaged in the process design, engineering construction, equipment supply, installation, and commissioning of this project.

Detailed Photos

Working Principle

Our Advantages

Product Parameters

Parameters	HYHJ-RO/EDI-5T
Machine Size(LWH)	6500mm/850mm/2200mm
Control mode	Fully automatic operation
Device power	AC/380V/50HZ
Raw water pump	Q=12m³/H H=30m
First-stage high-pressure pump	Q=12m³/H H=100m
Two-stage high-pressure pump	Q=8m³/H H=80m
Reverse osmosis membrane vessels	3 core 8 inches
EDI booster pump	Q=6m³/H H=30m
EDI module	5000L/H
Quartz sand filter	φ1000×2200mm
Activated carbon filter	φ1000×2200mm
Precision filters	7 core 40 inches
Precision filter element	40''5μm
Scale inhibitor/PH dosing pump	Q=1L/H H=50m
Scale inhibitor/PH dosing box	40L
Primary reverse osmosis membrane	8040
Secondary reverse osmosis membrane model	8040

Product Application
